Le Medical

● 12.1 inch color display with 800*600 resolution.
● Three Working Modes: Monitoring, Surgery and Diagnosis.
● Simple and friendly operating display interface.
● Multi-display modes suitable for different applications:
● Standard Interface, Large font, ECG Standard Full Display,OXY , Trend Table, BP Trend.
● Built-in rechargeable Lithium battery up to 3 hours of continuous work
● VGA output for external display

ECG
● Lead Mode: 5 Leads (I, II, III, AVR, AVL,AVF, V)
● Gain: 2.5mm/mV, 5.0mm/mV, 10mm/mV, 20mm/mV
● Heart Rate: 15-300 BPM (Adult); 15-350 BPM (Neonatal)
● Resolution: 1 BPM
● Accuracy: ±1%
● Sensitivity >200 uV(Peak to peak)
● ST measurement range: -2.0 ~ +2.0 mV
● Accuracy: -0.8mV~+0.8mV: ±0.02mV or ±10%, which is greater
● Other Range: unspecified
● Sweep speed: 12.5 mm/s, 25mm/s, 50mm/s
● Bandwidth:
● Diagnostic: 0.05~130 Hz
● Monitor: 0.5~40 Hz
● Surgery: 1~20 Hz
