Le Medical

● Category：Specification
● Output：Biphasic Truncated exponential
● Energy Sequence(child)：10J-100J (option)
● Energy Sequence(Adult)：100J-360J (option)
● Charge Time：4 sec. to 200J7 sec. to 360 J(New battery)
● Analysis Time：6 sec.
● The maximum time from the initiation of rhythm analy-sis to readiness for discharge with a new battery.：Less than 10seconds
● The maximum time from the initiation of rhythm analy-sis to readiness for discharge after 6 shocks.：Less than 10 seconds
● The maximum time from initially switching power on to readiness for discharge.：Less than 15 seconds
● Visual Prompts：LED prompts;Automatic Self-test
● Controls Three buttons：Defibrillation, mode switching, language switching
● Output Energy Accuracy：±10% into any impedance from 25Ω to 175Ω
● The Maximum Voltage：2000V±50V
● Output disabled when the patient impedance is outsidelimits：20Ω to 200Ω

● Part No：CR123A-4×3
● Non-rechargeable：4200mAh
● Capacity：200 times discharges at 360 Joules
● Shelf Life (25℃+15C)：5 years standby (after installation)

● Dimensions：280 x 209 x 80 mm
● Weight：2.6 kg
● Operating Temperature：0°C to 40°C
● Operating Humidity：Relative humidity between 30% and 95%(non-condensing)
● Storage Temperature (without battery)：-20°C to 55°C
● Storage Humidity (without battery)：Up to 93%(non-condensing)
