● Output：Biphasic Truncated exponential
● Energy Sequence(child)：50J,50J,50J
● Energy Sequence(Adult)：150J,200J,200J
● Charge Time：4 sec. to 150J6 sec. to 200 J(New battery)
● Analysis Time：≤ 6 sec.
● The maximum time from the initiation of rhythm analy-sis to readiness for discharge with a new battery. ：Less than 10seconds
● The maximum time from the initiation of rhythm analy-sis to readiness for discharge after 6 shocks.：Less than 10 seconds
● The maximum time from initially switching power on to readiness for discharge.：Less than18 seconds
● Visual Prompts：LED prompts;Automatic Self-test
● Controls：Four buttons:On/Off, Shock, Adult/child, CPR
● Output Energy Accuracy：±10% into any impedance from 25Ω to 175Ω
● The Maximum Voltage：1800±50V
● Output disabled when the patient impedance is outsidelimits：20Ω to 200Ω

● Part No：CR123A-4×2
● Non-rechargeable：2800 mAh
● Capacity：200 times discharges at 200 Joules
● Shelf Life (25℃+15C)：5 years standby (after installation)

● Dimensions：280 x 209 x 80 mm
● Weight：2.5 kg
● Operating Temperature：0°C to 40°C
● Operating Humidity：Relative humidity between 30% and 95%(non-condensing)
● Storage Temperature (without battery)：-20°C to 55°C
● Storage Humidity (without battery)：Up to 93%(non-condensing)
